3150 |
| |
| Valve material |
Brass |
| Inlet/Outlet |
2 inches |
| Service flow rate (m3/h / gpm) |
22 / 97 |
| Backwash flow rate |
24 / 105 |
| Softener tank size |
24" - 60" |
| Filter tank size |
24" - 42 |
| Cycles |
Cycles: 5 |
| Electrical rating |
Electrical rating: 24 v, 110 v - 50 Hz, 60 Hz |
| Distributor pilot |
Distributor pilot: 2" pipe I.D. |
| Drain line |
Drain line: 2" NPTM |
| Injector brine system |
Injector brine system: 1" |
| Brine line |
Brine line: 1" |
| |
| Mounting base |
Mounting base: Top mount4" - 8 UN |
| Height from top of tank |
Height from top of tank: 10" |
| Hot water |
• |
| Timer type |
3200/ET/NXT |
| Adjustable cycles |
• |
| NBP piston |
• |
| Duplex |
• |
| Multiplex |
with NXT only |
